| TYPE | DESCRIPTION |
| Part Number: | BCR119WH6327XTSA1 |
| Description: | TRANS PREBIAS NPN 250MW SOT323-3 |
| Lead Free Status / RoHS Status: | |
| Supplier Device Package | PG-SOT323-3 |
| Other Names | BCR 119W H6327 ","BCR 119W H6327-ND ","BCR119WH6327XTSA1TR ","BCR119WH6327XTSA1TR-NDTR-ND ","SP000755044 |
| Frequency - Transition | 150MHz |
| Detailed Description | Pre-Biased Bipolar Transistor (BJT) NPN - Pre-Biased 50V 100mA 150MHz 250mW Surface Mount PG-SOT323-3 |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Power - Max | 250mW |
| Meta Part Number | BCR119WH6327XTSA1TR-ND |
| Package / Case | SC-70, SOT-323 |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 120 @ 5mA, 5V |
| Transistor Type | NPN - Pre-Biased |
| Current - Collector (Ic) (Max) | 100mA |
| Current - Collector Cutoff (Max) | 100nA (ICBO) |
| Series | - |
| Resistor - Base (R1) | 4.7 kOhms |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Vce Saturation (Max) @ Ib, Ic | 300mV @ 500µA, 10mA |
| Voltage - Collector Emitter Breakdown (Max) | 50V |
| Mounting Type | Surface Mount |
| Base Part Number | BCR119 |
| Packaging | Tape & Reel (TR) |
