| TYPE | DESCRIPTION |
| Part Number: | PDTA143XE,135 |
| Description: | TRANS PREBIAS PNP 150MW SC75 |
| Lead Free Status / RoHS Status: | |
| Resistor - Emitter Base (R2) | 10 kOhms |
| Current - Collector (Ic) (Max) | 100mA |
| Mounting Type | Surface Mount |
| Packaging | Tape & Reel (TR) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 50 @ 10mA, 5V |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Detailed Description | Pre-Biased Bipolar Transistor (BJT) PNP - Pre-Biased 50V 100mA 150mW Surface Mount SC-75 |
| Resistor - Base (R1) | 4.7 kOhms |
| Current - Collector Cutoff (Max) | 1µA |
| Base Part Number | PDTA143 |
| Package / Case | SC-75, SOT-416 |
| Vce Saturation (Max) @ Ib, Ic | 150mV @ 500µA, 10mA |
| Other Names | 934055281135 ","PDTA143XE /T3 ","PDTA143XE /T3-ND |
| Voltage - Collector Emitter Breakdown (Max) | 50V |
| Meta Part Number | PDTA143XE,135-ND |
| Power - Max | 150mW |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Supplier Device Package | SC-75 |
| Series | - |
| Transistor Type | PNP - Pre-Biased |
