Категория
Transistors - FETs, MOSFETs - Arrays
Производитель
Diodes Incorporated
RoHS
YES
Certification
Доставка
Оплата
| TYPE | DESCRIPTION |
| Part Number: | DMN1003UCA6-7 |
| Description: | MOSFET 2 N-CHANNEL X3-DSN3518-6 |
| Lead Free Status / RoHS Status: | |
| Packaging | Cut Tape (CT) |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Detailed Description | Mosfet Array 2 N-Channel (Dual) 2.67W Surface Mount X3-DSN3518-6 |
| Package / Case | 6-SMD, No Lead |
| Mounting Type | Surface Mount |
| Meta Part Number | DMN1003UCA6-7DICT-ND |
| Current - Continuous Drain (Id) @ 25°C | - |
| Drain to Source Voltage (Vdss) | - |
| FET Type | 2 N-Channel (Dual) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Input Capacitance (Ciss) (Max) @ Vds | 3315pF @ 6V |
| Rds On (Max) @ Id, Vgs | - |
| Gate Charge (Qg) (Max) @ Vgs | 56.5nC @ 4.5V |
| Power - Max | 2.67W |
| Other Names | DMN1003UCA6-7DICT |
| Supplier Device Package | X3-DSN3518-6 |
| Series | - |
| FET Feature | Standard |
| Vgs(th) (Max) @ Id | 1.3V @ 1mA |
| Manufacturer Standard Lead Time | 20 Weeks |
| Operating Temperature | -55°C ~ 150°C (TJ) |
Таблицы данных: Work in prgress, stay tuned!
