Категория
Transistors - FETs, MOSFETs - Arrays
Производитель
Electro-Films (EFI) / Vishay
RoHS
YES
Certification
Доставка
Оплата
| TYPE | DESCRIPTION |
| Part Number: | SI3850ADV-T1-E3 |
| Description: | MOSFET N/P-CH 20V 1.4A 6TSOP |
| Lead Free Status / RoHS Status: | |
| Base Part Number | SI3850 |
| Input Capacitance (Ciss) (Max) @ Vds | - |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| FET Feature | Logic Level Gate |
| Gate Charge (Qg) (Max) @ Vgs | 1.4nC @ 4.5V |
| Power - Max | 1.08W |
| Rds On (Max) @ Id, Vgs | 300 mOhm @ 500mA, 4.5V |
| Series | TrenchFET® |
| Current - Continuous Drain (Id) @ 25°C | 1.4A, 960mA |
| Drain to Source Voltage (Vdss) | 20V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Packaging | Cut Tape (CT) |
| Package / Case | SOT-23-6 Thin, TSOT-23-6 |
| Vgs(th) (Max) @ Id | 1.5V @ 250µA |
| Meta Part Number | SI3850ADV-T1-E3CT-ND |
| FET Type | N and P-Channel, Common Drain |
| Other Names | SI3850ADV-T1-E3CT SI3850ADVT1E3 |
| Mounting Type | Surface Mount |
| Supplier Device Package | 6-TSOP |
| Detailed Description | Mosfet Array N and P-Channel, Common Drain 20V 1.4A, 960mA 1.08W Surface Mount 6-TSOP |
Таблицы данных: Work in prgress, stay tuned!
