Категория
Thyristors - SCRs
Производитель
IXYS / Littelfuse
RoHS
YES
Certification
Доставка
Оплата
| TYPE | DESCRIPTION |
| Part Number: | CS23-08IO2 |
| Description: | SCR PHASE CONTROL 800V 25A TO-48 |
| Lead Free Status / RoHS Status: | |
| Detailed Description | SCR 800V 50A Standard Recovery Chassis, Stud Mount TO-208AA (TO-48) |
| Voltage - On State (Vtm) (Max) | 1.8V |
| Current - Hold (Ih) (Max) | 100mA |
| Other Names | CS2308IO2 |
| Current - Off State (Max) | 3mA |
| Packaging | Bulk |
| Mounting Type | Chassis, Stud Mount |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Current - On State (It (AV)) (Max) | 32A |
| Meta Part Number | CS23-08IO2-ND |
| Current - On State (It (RMS)) (Max) | 50A |
| Series | - |
| Operating Temperature | -40°C ~ 125°C |
| Package / Case | TO-208AA, TO-48-3, Stud |
| Voltage - Gate Trigger (Vgt) (Max) | 2.5V |
| Current - Gate Trigger (Igt) (Max) | 50mA |
| Manufacturer Standard Lead Time | 32 Weeks |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 450A, 480A |
| SCR Type | Standard Recovery |
| Voltage - Off State | 800V |
| Supplier Device Package | TO-208AA (TO-48) |
Таблицы данных: Work in prgress, stay tuned!
