Категория
Diodes - Rectifiers - Single
Производитель
Taiwan Semiconductor
RoHS
YES
Certification
Доставка
Оплата
| TYPE | DESCRIPTION |
| Part Number: | MUR420S R7G |
| Description: | DIODE GEN PURP 200V 4A DO214AB |
| Lead Free Status / RoHS Status: | |
| Diode Type | Standard |
| Package / Case | DO-214AB, SMC |
| Series | - |
| Voltage - Forward (Vf) (Max) @ If | 875mV @ 4A |
| Mounting Type | Surface Mount |
| Current - Reverse Leakage @ Vr | 5µA @ 200V |
| Other Names | MUR420S R7GTR ","MUR420S R7GTR-ND ","MUR420SR7GTR |
| Speed | Fast Recovery = 200mA (Io) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Supplier Device Package | DO-214AB (SMC) |
| Detailed Description | Diode Standard 200V 4A Surface Mount DO-214AB (SMC) |
| Meta Part Number | MUR420SR7GTR-ND |
| Capacitance @ Vr, F | 65pF @ 4V, 1MHz |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Current - Average Rectified (Io) | 4A |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Voltage - DC Reverse (Vr) (Max) | 200V |
| Packaging | Tape & Reel (TR) |
| Reverse Recovery Time (trr) | 25ns |
Таблицы данных: Work in prgress, stay tuned!
