Категория
Transistors - Bipolar (BJT) - RF
Производитель
Freescale / NXP Semiconductors
RoHS
YES
Certification
Доставка
Оплата
| TYPE | DESCRIPTION |
| Part Number: | BFU550WF |
| Description: | TRANS RF NPN 12V 50MA SOT-323 |
| Lead Free Status / RoHS Status: | |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Detailed Description | RF Transistor NPN 12V 50mA 11GHz 450mW Surface Mount SOT-323-3 |
| Current - Collector (Ic) (Max) | 50mA |
| Other Names | 934067695135 |
| Series | - |
| Supplier Device Package | SOT-323-3 |
| Packaging | Tape & Reel (TR) |
| Frequency - Transition | 11GHz |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Meta Part Number | BFU550WF-ND |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 60 @ 15mA, 8V |
| Transistor Type | NPN |
| Power - Max | 450mW |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Voltage - Collector Emitter Breakdown (Max) | 12V |
| Package / Case | SC-70, SOT-323 |
| Noise Figure (dB Typ @ f) | 1.3dB @ 1.8GHz |
| Mounting Type | Surface Mount |
| Base Part Number | BFU550 |
| Gain | 12dB |
Таблицы данных: Work in prgress, stay tuned!
