Категория
Diodes - Rectifiers - Single
Производитель
Electro-Films (EFI) / Vishay
RoHS
YES
Certification
Доставка
Оплата
| TYPE | DESCRIPTION |
| Part Number: | AR4PDHM3_A/I |
| Description: | DIODE AVALANCHE 200V 2A TO277A |
| Lead Free Status / RoHS Status: | |
| Current - Average Rectified (Io) | 2A |
| Packaging | Tape & Reel (TR) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Supplier Device Package | TO-277A (SMPC) |
| Voltage - Forward (Vf) (Max) @ If | 1.6V @ 4A |
| Operating Temperature - Junction | -55°C ~ 175°C |
| Voltage - DC Reverse (Vr) (Max) | 200V |
| Detailed Description | Diode Avalanche 200V 2A Surface Mount TO-277A (SMPC) |
| Reverse Recovery Time (trr) | 140ns |
| Mounting Type | Surface Mount |
| Package / Case | TO-277, 3-PowerDFN |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Manufacturer Standard Lead Time | 44 Weeks |
| Diode Type | Avalanche |
| Capacitance @ Vr, F | 77pF @ 4V, 1MHz |
| Speed | Fast Recovery = 200mA (Io) |
| Meta Part Number | AR4PDHM3_A/I-ND |
| Current - Reverse Leakage @ Vr | 10µA @ 200V |
| Series | Automotive, AEC-Q101, eSMP® |
Таблицы данных: Work in prgress, stay tuned!
